Flight Plan partially loaded on Cessna Citation CJ4

Bug Reporting Hub Aircraft & Systems
, , , , ,
1

Using the template below will greatly help the team reproduce the issue and ease the process of fixing it. Before posting, search for an existing report. If you are not sure it’s a bug, please first report in User Support Hub.

3 tags are required - add them in the tag section next to the title above:

Feel free to delete this quote section after adding your appropriate tags.

ISSUE DESCRIPTION

The flight plan is only partially loaded into the aircraft avionics.

FREQUENCY OF ISSUE

100% all the times

REPRODUCTION STEPS

Please list clear steps you took in order to help our test team reproduce the same issue:

  1. using the official flight planner application create the flight plan from LIML to LIEE

  2. Send the plan from the EFB to ATC and Avionics

  3. The plan is only partially loaded

YOUR SETTINGS

Mfsfs2024 on PS5 base

MEDIA

2

Could you upload in your 1st post the .pln file you are having an issue with and mention which waypoints are missing ?
Detailed information in “Reproduction Steps” is key for devs and users to try to replicate.

3

I’m having the exacty same problem with PC (MS store). PLN file attached. When sending the plan to avionics, the plan is cut after OLIL5C/OLILA or after RUVAT (some randomness here?) and rest of the plan is missing, including destination.

Citation_plan_loading_problem.PLN (2.8 KB)

The flight plan was made with MS flight planner and it loads correctly to EFB.

4

Try creating the plan directly in the EFB as opposed to the Flight Planner website. The EFB draws directly from the sim AIRAC whereas there are some slight differences in the NavData on the web iirc.

5

Here’s minimal flight plan to reproduce the problem. The first one has waypoints TIMIB, LEGSA, GEVNI which is cut after TIMIB when sent to avionics. The second does not have LEGSA and the plan is imported correctly.

If you take a look at those files, the difference is the airway. Comparing to my previous message, also there the problem seems to be the airway-definition. At least that is cut in first ATCAirway-element, too.

Broken after timib.PLN (1.3 KB)
LEGSA removed.PLN (1.3 KB)

6

And one more comment… I tried doing the same stuff directly with EFB and not using the web planner. With EFB everything seems to work, also when selecting “victor airways” + “find route” which includes TIMIB, LEGSA, GEVNI in the same way as in the problematic case.

However, if I look at the PLN file, there is no ATCAirway-elements, only waypoints after waypoints. So obviously the EFB handles this case differently.

7

I don’t know if you can access this but in the FPL on board it load the plan only up to ITCAP waypoint.

In any case you can try also this string:

LIML TOVS7A ITCAP M858 TORTU A9 LIBLO DCT TOPDA DCT CORSI M858 RAMEN KOVAS KOVA1W LIEE

8

If this can help the developers , consider that this happens when the plan is loaded from the EFB “load from web” function in which I previously created and saved the plan on a PC.

if instead you create the plan using the EFB in game and you send it to ATC and Avionics , the whole plan is correctly loaded into the avionics.

So the bug is in the first case

9

Fully agree
