Thatās very interesting, itās the A320 I am using where I feel no turbulence at any time. But I just had a look into the flight mode.cfg and canāt find any reference to turbulence, but there is reference to other flight dynamics - see below I have reproduced the cfg
Now we have complete calm air above the cloudbase where the air should start to be turbulent because of the unstable mixing air inside those clouds. Hope they add that soon. That would make the air inside comulus or Cumulonimbus clouds feel more realistic. As it is now we can fly right through those types of clouds without notice or fair of danger. To me even add some unpredictable air movement would make it more realistic than it is now. Because turbulence is unpredictable and impossible to recreate 100% realistic. CFD in my opinion is the closest we would get if they are able to model ālarge eddyā
Iām 100% with this, as I say, Iām in the A320
A320 flight model.cfg follows:
[VERSION]
major = 1
minor = 0
[WEIGHT_AND_BALANCE]
max_gross_weight = 174165 ; Empty weight, (LBS)
empty_weight = 90400 ; Empty weight, (LBS)
reference_datum_position = 0, 0, 0 ; Position of reference datum relative to FS(0,0,0) (FEET), z, x, y
empty_weight_CG_position = -9, 0, -1 ; Position of airplane empty weight CG relative to reference datum (FEET), z, x, y
CG_forward_limit = 0.16 ; Gravity center forward limit (longitudinal offset) for longitudinal stability
CG_aft_limit = 0.4 ; Gravity center after limit (longitudinal offset z) w.r.t reference datum for longitudinal stability (FEET)
empty_weight_pitch_MOI = 3027957 ; Empty pitch moment of inertia, Jxx (SLUG SQ FEET)
empty_weight_roll_MOI = 840695 ; Empty roll moment of inertia, Jzz (SLUG SQ FEET)
empty_weight_yaw_MOI = 3507948 ; Empty yaw moment of inertia, Jyy (SLUG SQ FEET)
empty_weight_coupled_MOI = 1000 ; Empty transverse moment of inertia, Jyz (SLUG SQ FEET)
activate_mach_limit_based_on_cg = 0 ; Activate mach limitation depending on CG position (true if > 0 /false othewise). Mostly for Concorde).
activate_cg_limit_based_on_mach = 0 ; Activate cg limitation depending on mach value (true if > 0 /false othewise). Mostly for Concorde).
max_number_of_stations = 6 ; Number of payload stations
station_load.0 = 170, 35.59, -1.86, 5.017127, TT:MENU.PAYLOAD.PILOT, 1
station_load.1 = 170, 35.59, 1.86, 5.017127, TT:MENU.PAYLOAD.COPILOT, 2
station_load.2 = 6115, 20.845893, 0, 5.039792, TT:MENU.PAYLOAD.BUSINESS_CLASS, 0
station_load.3 = 3505, 21.825772, 0, 0.94849, TT:MENU.PAYLOAD.FORWARD_BAGGAGE, 0
station_load.4 = 4000, -21.223969, 0, 5.794459, TT:MENU.PAYLOAD.ECONOMY_CLASS, 0
station_load.5 = 6310, -35.825745, 0.000001, 1.007935, TT:MENU.PAYLOAD.REAR_BAGGAGE, 0
[CONTACT_POINTS]
static_pitch = -0.2 ; degrees, pitch when at rest on the ground (+=Up, -=Dn)
static_cg_height = 8.89 ; feet, altitude of CG when at rest on the ground
gear_system_type = 1 ; gear system type (betweeen 0 and 4) 0 = electrical, 1 = hydraulic, 2 = pneumatic, 3 = manual, 4 = none, 5 = undefined
tailwheel_lock = 0 ; Is tailwheel lock available TRUE/FALSE
max_number_of_points = 14 ; Number of contact points
gear_locked_on_ground = 0 ; Defines whether or not the landing gear handle is locked to down when the plane is on the ground.
gear_locked_above_speed = -1 ; Defines the speed at which the landing gear handle becomes locked in the up position. (-1 = Disabled)
max_speed_full_steering = 8 ; Defines the speed under which the full angle of steering is available (in feet/second).
max_speed_decreasing_steering = 50 ; Defines the speed above which the angle of steering stops decreasing (in feet/second).
min_available_steering_angle_pct = 0.2 ; Defines the percentage of steering which will always be available even above max_speed_decreasing_steering (in percent over 100).
max_speed_full_steering_castering = 20 ; Defines the speed under which the full angle of steering is available for free castering wheels (in feet/second).
max_speed_decreasing_steering_castering = 40 ; Defines the speed above which the angle of steering stops decreasing for free castering wheels (in feet/second).
min_castering_angle = 0.05236 ; Defines the minimum angle a free castering wheel can take (in radians).
max_castering_angle = 3.14159265358979 ; Defines the maximum angle a free castering wheel can take (in radians).
point.0 = 1, 27.1, 0, -9.3, 720, 0, 1.68, 75, 0.555, 2, 0.33, 9, 9.4, 0, 0, 0, 2
point.1 = 1, -13, -14, -9.58, 1500, 1, 1.68, 0, 0.637, 2, 0.33, 9.7, 9, 2, 0, 0, 2
point.2 = 1, -13, 14, -9.58, 1500, 2, 1.68, 0, 0.637, 2, 0.33, 9.2, 9.9, 3, 0, 0, 2
point.3 = 2, -26, -57, 6, 350, 0, 0, 0, 0, 0, 0, 0, 0, 5, 0, 0, 1
point.4 = 2, -26, 57, 6, 350, 0, 0, 0, 0, 0, 0, 0, 0, 6, 0, 0, 1
point.5 = 2, 44.351583, -0, 2.234261, 350, 0, 0, 0, 0, 0, 0, 0, 0, 4, 0, 0, 1
point.6 = 2, 30.599106, 0, -2.125757, 500, 0, 0, 0, 0, 0, 0, 0, 0, 4, 0, 0, 1
point.7 = 2, 22.658546, 0.000002, 11.482972, 1, 0, 0, 0, 0, 0, 0, 0, 0, 4, 0, 0, 1
point.8 = 2, 2.333118, -18.801452, -6.863951, 500, 0, 0, 0, 0, 0, 0, 0, 0, 5, 0, 0, 1
point.9= 2, 2.333118, 18.801452, -6.863951, 500, 0, 0, 0, 0, 0, 0, 0, 0, 6, 0, 0, 1
point.10= 2, -32.268314, -0.000003, -2.125712, 500, 0, 0, 0, 0, 0, 0, 0, 0, 4, 0, 0, 1
point.11= 2, -68, 0, 4.1, 750, 0, 0, 0, 0, 0, 0, 0, 0, 7, 0, 0, 1
point.12= 2, -75.199786, 0, 30.442432, 350, 0, 0, 0, 0, 0, 0, 0, 0, 8, 0, 0, 1
point.13= 2, -79.2, 0, 8, 350, 0, 0, 0, 0, 0, 0, 0, 0, 9, 0, 0, 1
[FUEL]
LeftMain = -9, -13, 2, 1800, 0 ; For each tank: Tank position (z longitudinal, x lateral, y vertical) (FEET), total fuel capacity (GALLONS), unusable fuel capacity (GALLONS)
RightMain = -9, 13, 2, 1800, 0
Center1 = -11, 0, 1, 3000, 0
Center2 = 0, 0, 0, 0, 0
Center3 = 0, 0, 0, 0, 0
LeftAux = -13, -27, 3, 200, 0
LeftTip = 0, 0, 0, 0, 0
RightAux = -13, 27, 3, 200, 0
RightTip = 0, 0, 0, 0, 0
External1 = 0, 0, 0, 0, 0
External2 = 0, 0, 0, 0, 0
fuel_type = 2 ; 1 = OCTANE 100, 2 = JET_A, 3 = OCTANE 80, 4 = AUTO GAS, 5 = JET B
number_of_tank_selectors = 1 ; Max 4
electric_pump = 0
engine_driven_pump = 1
manual_transfer_pump = 0
manual_pump = 0
anemometer_pump = 0
fuel_dump_rate = 0.02
default_fuel_tank_selector.1 = 1 ; Default fuel selector used in case of autostart for engine 1, default is ALL.
default_fuel_tank_selector.2 = 1 ; Default fuel selector used in case of autostart for engine 2, default is ALL.
default_fuel_tank_selector.3 = 1 ; Default fuel selector used in case of autostart for engine 3, default is ALL.
default_fuel_tank_selector.4 = 1 ; Default fuel selector used in case of autostart for engine 4, default is ALL.
[FUEL_SYSTEM]
Version = Latest
APU.1 = Name:APU#FuelBurnRate:33
Engine.1 = Name:LeftEngine#Index:1
Engine.2 = Name:RightEngine#Index:2
Tank.1 = Name:Center#Title:TT:MENU.FUEL.CENTER#Capacity:3000#UnusableCapacity:0#Position:-6,0,1#Priority:1#OutputOnlyLines:TankCenterToCenterTankPump1,TankCenterToCenterTankPump2
Tank.2 = Name:LeftInner#Title:TT:MENU.FUEL.LEFT_INNER#Capacity:1800#UnusableCapacity:0#Position:-8,-13,2#Priority:2#InputOnlyLines:Eng1ToTank2,Xfer1ToTank2,Xfer1ToTank2_2#OutputOnlyLines:TankLeftToLeftTankPump1,TankLeftToLeftTankPump2
Tank.3 = Name:RightInner#Title:TT:MENU.FUEL.RIGHT_INNER#Capacity:1800#UnusableCapacity:0#Position:-8,13,2#Priority:2#InputOnlyLines:Eng2ToTank3,Xfer2ToTank3,Xfer2ToTank3_2#OutputOnlyLines:TankRightToRightTankPump1,TankRightToRightTankPump2
Tank.4 = Name:LeftOuter#Title:TT:MENU.FUEL.LEFT_OUTER#Capacity:200#UnusableCapacity:0#Position:-13,-27,3#Priority:3#OutputOnlyLines:Tank4ToXfer1,Tank4ToXfer1_2
Tank.5 = Name:RightOuter#Title:TT:MENU.FUEL.RIGHT_OUTER#Capacity:200#UnusableCapacity:0#Position:-13,27,3#Priority:3#OutputOnlyLines:Tank5ToXfer2,Tank5ToXfer2_2
Line.1 = Name:TankCenterToCenterTankPump1#Source:Center#Destination:CenterTankPump1
Line.2 = Name:TankLeftToLeftTankPump1#Source:LeftInner#Destination:LeftInnerTankPump1
Line.3 = Name:TankRightToRightTankPump1#Source:RightInner#Destination:RightInnerTankPump1
Line.4 = Name:TankCenterToCenterTankPump2#Source:Center#Destination:CenterTankPump2
Line.5 = Name:TankLeftToLeftTankPump2#Source:LeftInner#Destination:LeftInnerTankPump2
Line.6 = Name:TankRightToRightTankPump2#Source:RightInner#Destination:RightInnerTankPump2
Line.7 = Name:PumpCenterToJuncLeftCenter#Source:CenterTankPump1#Destination:CenterLeftJunction
Line.8 = Name:PumpLeft1ToJuncLeft#Source:LeftInnerTankPump1#Destination:LeftJunction
Line.9 = Name:PumpRight1ToJuncRight#Source:RightInnerTankPump1#Destination:RightJunction
Line.10 = Name:PumpCenter2ToJuncRightCenter#Source:CenterTankPump2#Destination:CenterRightJunction
Line.11 = Name:PumpLeft2ToJuncLeft#Source:LeftInnerTankPump2#Destination:LeftJunction
Line.12 = Name:PumpRight2ToJuncRight#Source:RightInnerTankPump2#Destination:RightJunction
Line.13 = Name:Junc1ToEngValveLeft#Source:LeftJunction#Destination:LeftEngineValve
Line.14 = Name:Junc2ToEngValveRight#Source:RightJunction#Destination:RightEngineValve
Line.15 = Name:JuncAPUToAPUPump#Source:APUJunction#Destination:APUPump
Line.16 = Name:Junc1ToJuncAPU#Source:LeftJunction#Destination:APUJunction
Line.17 = Name:JuncAPUToJunc3#Source:APUJunction#Destination:CenterLeftJunction
Line.18 = Name:Junc3ToXFeed#Source:CenterLeftJunction#Destination:CrossFeedValve
Line.19 = Name:Junc4ToXFeed#Source:CenterRightJunction#Destination:CrossFeedValve
Line.20 = Name:Junc2ToJunc4#Source:RightJunction#Destination:CenterRightJunction
Line.21 = Name:Pump6ToAPUValve#Source:APUPump#Destination:APUValve
Line.22 = Name:APUValveToAPU#Source:APUValve#Destination:APU
Line.23 = Name:Eng1ToTank2#Source:LeftEngine#Destination:LeftInner
Line.24 = Name:Eng2ToTank3#Source:RightEngine#Destination:RightInner
Line.25 = Name:EngValveLeftToEngLeft#Source:LeftEngineValve#Destination:LeftEngine
Line.26 = Name:EngValveRightToEngRight#Source:RightEngineValve#Destination:RightEngine
Line.27 = Name:Tank4ToXfer1#Source:LeftOuter#Destination:LeftTransferValve1#GravityBasedFuelFlow:500
Line.28 = Name:Tank5ToXfer2#Source:RightOuter#Destination:RightTransferValve1#GravityBasedFuelFlow:500
Line.29 = Name:Xfer1ToTank2#Source:LeftTransferValve1#Destination:LeftInner#GravityBasedFuelFlow:500
Line.30 = Name:Xfer2ToTank3#Source:RightTransferValve1#Destination:RightInner#GravityBasedFuelFlow:500
Line.31 = Name:Tank4ToXfer1_2#Source:LeftOuter#Destination:LeftTransferValve2#GravityBasedFuelFlow:500
Line.32 = Name:Tank5ToXfer2_2#Source:RightOuter#Destination:RightTransferValve2#GravityBasedFuelFlow:500
Line.33 = Name:Xfer1ToTank2_2#Source:LeftTransferValve2#Destination:LeftInner#GravityBasedFuelFlow:500
Line.34 = Name:Xfer2ToTank3_2#Source:RightTransferValve2#Destination:RightInner#GravityBasedFuelFlow:500
Junction.1 = Name:LeftJunction#InputOnlyLines:PumpLeft1ToJuncLeft,PumpLeft2ToJuncLeft#OutputOnlyLines:Junc1ToEngValveLeft,Junc1ToJuncAPU
Junction.2 = Name:RightJunction#InputOnlyLines:PumpRight1ToJuncRight#OutputOnlyLines:Junc2ToEngValveRight
Junction.3 = Name:CenterLeftJunction#InputOnlyLines:PumpCenterToJuncLeftCenter
Junction.4 = Name:CenterRightJunction#InputOnlyLines:PumpCenter2ToJuncRightCenter
Junction.5 = Name:APUJunction#OutputOnlyLines:JuncAPUToAPUPump
Valve.1 = Name:LeftEngineValve#OpeningTime:3#Circuit:1
Valve.2 = Name:RightEngineValve#OpeningTime:3#Circuit:2
Valve.3 = Name:CrossFeedValve#OpeningTime:3#Circuit:3
Valve.4 = Name:LeftTransferValve2#Circuit:4
Valve.5 = Name:RightTransferValve2#Circuit:5
Valve.6 = Name:LeftTransferValve1#Circuit:6
Valve.7 = Name:RightTransferValve1#Circuit:7
Valve.8 = Name:APUValve#OpeningTime:3#Circuit:8
Pump.1 = Name:CenterTankPump1#Pressure:29#DestinationLine:PumpCenterToJuncLeftCenter#TankFuelRequired:Center#Type:Electric#Index:1
Pump.2 = Name:LeftInnerTankPump1#Pressure:25#DestinationLine:PumpLeft1ToJuncLeft#TankFuelRequired:LeftInner#Type:Electric#Index:3
Pump.3 = Name:RightInnerTankPump1#Pressure:25#DestinationLine:PumpRight1ToJuncRight#TankFuelRequired:RightInner#Type:Electric#Index:4
Pump.4 = Name:CenterTankPump2#Pressure:29#DestinationLine:PumpCenter2ToJuncRightCenter#TankFuelRequired:Center#Type:Electric#Index:2
Pump.5 = Name:LeftInnerTankPump2#Pressure:25#DestinationLine:PumpLeft2ToJuncLeft#TankFuelRequired:LeftInner#Type:Electric#Index:5
Pump.6 = Name:RightInnerTankPump2#Pressure:25#DestinationLine:PumpRight2ToJuncRight#TankFuelRequired:RightInner#Type:Electric#Index:6
Pump.7 = Name:APUPump#Pressure:5#DestinationLine:Pump6ToAPUValve#TankFuelRequired:LeftInner#Type:APUDriven
Trigger.1 = Target:LeftInner#Threshold:250#Condition:TankQuantityBelow#EffectTrue:OpenValve.LeftTransferValve1,OpenValve.LeftTransferValve2#EffectFalse:CloseValve.LeftTransferValve1,CloseValve.LeftTransferValve2
Trigger.2 = Target:RightInner#Threshold:250#Condition:TankQuantityBelow#EffectTrue:OpenValve.RightTransferValve1,OpenValve.RightTransferValve2#EffectFalse:CloseValve.RightTransferValve1,CloseValve.RightTransferValve2
Trigger.3 = Condition:Autostart_Enabled#EffectTrue:OpenValve.LeftEngineValve,OpenValve.RightEngineValve,OpenValve.CrossFeedValve,OpenValve.APUValve,StartPump.CenterTankPump1,StartPump.LeftInnerTankPump1,StartPump.RightInnerTankPump1,StartPump.CenterTankPump2,StartPump.LeftInnerTankPump2,StartPump.RightInnerTankPump2,StartPump.APUPump
Trigger.4 = Condition:Autoshutdown_Enabled#EffectTrue:CloseValve.LeftEngineValve,CloseValve.RightEngineValve,CloseValve.CrossFeedValve,CloseValve.APUValve,StopPump.CenterTankPump1,StopPump.LeftInnerTankPump1,StopPump.RightInnerTankPump1,StopPump.CenterTankPump2,StopPump.LeftInnerTankPump2,StopPump.RightInnerTankPump2
[AIRPLANE_GEOMETRY]
wing_area = 1313.2 ; Wing area S (SQUARE FEET)
wing_span = 117.454 ; Wing span b (FEET)
wing_root_chord = 21 ; Wing root chord croot (FEET)
wing_camber = 1 ; (DEGREES)
wing_thickness_ratio = 0.02 ; Local thickness is local_chord(x)*wing_thickness_ratio, x = lateral coord
wing_dihedral = 7 ; Dihedral angle Lambda (DEGREES)
wing_incidence = 2 ; Wing incidence (DEGREES)
wing_twist = -2 ; Wing twist epsilon (DEGREES)
oswald_efficiency_factor = 0.75 ; Wing Oswald efficiency factor e (non dimensional)
wing_winglets_flag = 0 ; Has winglets true/false
wing_sweep = 28 ; Wing sweep (DEGREES)
wing_pos_apex_lon = 0 ; Longitudinal (z) position of wing apex w.r.t reference datum (FEET)
wing_pos_apex_vert = 0 ; Vertical (y) position of wing apex w.r.t reference datum (FEET)
htail_area = 200 ; Horizontal tail area (SQUARE FEET)
htail_span = 41.3 ; Horizontal tail span (FEET)
htail_pos_lon = -68 ; Longitudinal (z) position of horizontal tail w.r.t reference datum (FEET)
htail_pos_vert = 8 ; Vertical (y) position of horizontal tail w.r.t reference datum (FEET)
htail_incidence = 0 ; Horizontal tail incidence (DEGREES)
htail_sweep = 30 ; Horizontal tail sweep angle (DEGREES)
htail_thickness_ratio = 0.02 ; Local thickness is local_chord(x)*htail_thickness_ratio, x = lateral coord
vtail_area = 250 ; Vertical tail area (SQUARE FEET)
vtail_span = 22.0 ; Vertical tail span (FEET)
vtail_sweep = 35 ; Vertical tail sweep angle (DEGREES)
vtail_pos_lon = -60 ; Longitudinal (z) position of vertical tail w.r.t reference datum (FEET)
vtail_pos_vert = 19.5 ; Vertical (y) position of vertical tail w.r.t reference datum (FEET)
vtail_thickness_ratio = 0.03 ; Local thickness is local_chord(x)*vtail_thickness_ratio, x = lateral coord
fuselage_length = 119 ; Nose to tail (FEET)
fuselage_diameter = 13
fuselage_center_pos = -7, 0, 5
elevator_area = 200 ; Elevator area (SQUARE FEET)
aileron_area = 31 ; Elevator area (SQUARE FEET)
rudder_area = 150 ; Elevator area (SQUARE FEET)
elevator_up_limit = 16 ; Elevator max deflection up angle (DEGREES)
elevator_down_limit = 11.5 ; Elevator max deflection down angle (absolute value) (DEGREES)
aileron_up_limit = 17 ; Aileron max deflection angle (DEGREES)
aileron_down_limit = 17 ; Aileron max deflection down angle (absolute value) (DEGREES)
rudder_limit = 25 ; Rudder max deflection angle (absolute value) (DEGREES)
rudder_trim_limit = 20 ; Rudder trim max deflection angle (absolute value) (DEGREES)
elevator_trim_limit = 13.5 ; Elevator trim max angle (absolute value) (DEGREES)
spoiler_limit = 35 ; Spoiler max deflection angle (absolute value) (DEGREES)
spoilerons_available = 1 ; Aircraft has spoilerons true/false
aileron_to_spoileron_gain = 0.5 ; Aileron influence on spoileron angle (non-dimensional)
min_ailerons_for_spoilerons = 2 ; Minimum aileron deflection (absolute value) in which spoilerons are active (DEGREES)
min_flaps_for_spoilerons = 0 ; Minimum flaps deflection (absolute value) in which spoilerons are active (DEGREES)
spoiler_extension_time = 2 ; Spoilers extension time (SECONDS)
spoiler_handle_available = 1 ; Spoiler handles available true/false
auto_spoiler_available = 1 ; Auto spoilers available true/false
auto_spoiler_auto_retracts = 0 ; Auto spoilers retracts automatically true/false
auto_spoiler_min_speed = 72 ; Auto spoilers minimum trigger speed
positive_g_limit_flaps_up = 2.5 ; Flap positive load limit when up. Same dimension as gravity vector FEET/SECONDS^2
positive_g_limit_flaps_down = 2.0 ; Flap positive load limit when down. Same dimension as gravity vector FEET/SECONDS^2
negative_g_limit_flaps_up = -0.5 ; Flap negative load limit when up. Same dimension as gravity vector FEET/SECONDS^2
negative_g_limit_flaps_down = 0.0 ; Flap negative load limit when down. Same dimension as gravity vector FEET/SECONDS^2
load_safety_factor = 1.5 ; Flap negative load limit when down. Same dimension as gravity vector FEET/SECONDS^2
elevator_trim_neutral = 0 ; Elevator trim max angle (absolute value) (DEGREES), for indicators only (no influence on flight model)
aileron_to_rudder_scale = 0 ; non-dimensional
flap_to_aileron_scale = 0 ; non-dimensional
fly_by_wire = 1 ; Fly-by-wire available true/false
elevator_elasticity_table = 0:1, 90:1, 250:0.9, 400:0.33
aileron_elasticity_table = 0:1, 90:1, 250:0.9, 400:0.33
rudder_elasticity_table = 0:1, 90:1, 250:0.9, 400:0.33
elevator_trim_elasticity_table = 0:1, 120:1, 250:0.9, 400:0.33
[AERODYNAMICS]
lift_coef_pitch_rate = -56.44798
lift_coef_daoa = 0.0
lift_coef_delta_elevator = -1.36067
lift_coef_horizontal_incidence = 0.0
lift_coef_flaps = 1.45380
lift_coef_spoilers = -0.30000
drag_coef_zero_lift = 0.02370
drag_coef_flaps = 0.15660
drag_coef_gear = 0.00500
drag_coef_spoilers = 0.15000
side_force_slip_angle = -3.54837
side_force_roll_rate = 1.71474
side_force_yaw_rate = 16.44880
side_force_delta_rudder = -2.92004
pitch_moment_horizontal_incidence = 0.0
pitch_moment_delta_elevator = -8.04390
pitch_moment_delta_trim = -8.04390
pitch_moment_pitch_damping = -1241.55249
pitch_moment_aoa_0 = -0.06641
pitch_moment_daoa = 0.0
pitch_moment_flaps = -0.12644
pitch_moment_gear = 0.00242
pitch_moment_spoilers = -0.09285
pitch_moment_delta_elevator_propwash = -2.01097
pitch_moment_pitch_propwash = 0.0
roll_moment_slip_angle = 0.52834
roll_moment_roll_damping = -2.01329
roll_moment_yaw_rate = -2.56504
roll_moment_spoilers = 0.0
roll_moment_delta_aileron = -0.18040
roll_moment_delta_rudder = 0.35539
roll_moment_delta_aileron_trim_scalar = -0.18040
yaw_moment_slip_angle = 1.49268
yaw_moment_roll = 0.68628
yaw_moment_yaw_damping = -38.40968
yaw_moment_yaw_propwash = 0.0
yaw_moment_delta_aileron = -0.00458
yaw_moment_delta_rudder = 0.98642
yaw_moment_delta_rudder_propwash = 0.24660
yaw_moment_delta_rudder_trim_scalar = 0.98642
compute_aero_center = 0
aero_center_lift = -8.75000
lift_coef_aoa_table = -3.15:0, -0.8:-1.231, -0.4:-0.917, -0.2:-0.772, -0.1:-0.246, 0:0.300, 0.20:1.118, 0.23:1.183, 0.26:1.231, 0.29:1.224, 0.31:1.071, 0.4:0.917, 0.8:1.240, 3.15:0
lift_coef_ground_effect_mach_table = 0.054:1.1
lift_coef_mach_table = 0:1
lift_coef_delta_elevator_mach_table = 0:0
lift_coef_daoa_mach_table = 0:0
lift_coef_pitch_rate_mach_table = 0:0
lift_coef_horizontal_incidence_mach_table = 0:0
drag_coef_zero_lift_mach_tab = 0:0.000, 0.5:0.000, 0.55:0.000, 0.6:0.000, 0.65:0.000, 0.7:0.000, 0.75:0.000, 0.8:0.000, 0.85:0.000, 0.9:0.150, 0.95:0.333, 1.0:0.500, 1.1:0.265, 1.5:0.030
side_force_slip_angle_mach_table = 0:0
side_force_delta_rudder_mach_table = 0:0
side_force_yaw_rate_mach_table = 0:0
side_force_roll_rate_mach_table = 0:0
pitch_moment_aoa_table = -3.15:0, -0.8:-2.029, -0.4:-1.007, -0.2:-0.933, -0.1:-0.599, 0:0, 0.20:1.064, 0.23:1.098, 0.26:1.086, 0.29:1.051, 0.31:1.088, 0.4:1.068, 0.8:2.011, 3.15:0
pitch_moment_delta_elevator_aoa_table = -180:-1, -40:0.189, -20:0.320, -14:0.788, -7:0.967, 0:1, 7:0.982, 14:0.902, 20:0.395, 40:0.171, 180:-1
pitch_moment_horizontal_incidence_aoa_table = 0:1
pitch_moment_daoa_aoa_table = 0:1
pitch_moment_pitch_alpha_table = 0:1
pitch_moment_delta_elevator_mach_table = 0:0
pitch_moment_daoa_mach_table = 0:0
pitch_moment_pitch_rate_mach_table = 0:0
pitch_moment_horizontal_incidence_mach_table = 0:0
pitch_moment_aoa_0_mach_table = 0:0
roll_moment_aoa_table = 0:0
roll_moment_slip_angle_aoa_table = 0:1
roll_moment_roll_rate_aoa_table = 0:1
roll_moment_delta_aileron_aoa_table = 0:1
roll_moment_slip_angle_mach_table = 0:0
roll_moment_delta_rudder_mach_table = 0:0
roll_moment_delta_aileron_mach_table = 0:0
roll_moment_yaw_rate_mach_table = 0:0
roll_moment_roll_rate_mach_table = 0:0
yaw_moment_aoa_table = 0:0
yaw_moment_slip_angle_aoa_table = 0:1
yaw_moment_yaw_rate_aoa_table = 0:1
yaw_moment_delta_rudder_aoa_table = 0:1
yaw_moment_slip_angle_mach_table = 0:0
yaw_moment_delta_rudder_mach_table = 0:0
yaw_moment_delta_aileron_mach_table = 0:0
yaw_moment_yaw_rate_mach_table = 0:0
yaw_moment_roll_rate_mach_table = 0:0
elevator_scaling_table = 0:1
aileron_scaling_table = 0:1
rudder_scaling_table = 0:1
aileron_load_factor_effectiveness_table = 0:1
lift_coef_at_drag_zero = 0.10000
lift_coef_at_drag_zero_flaps = 0.10000
[FLIGHT_TUNING]
modern_fm_only = 1
cruise_lift_scalar = 1
parasite_drag_scalar = 1
induced_drag_scalar = 1
flap_induced_drag_scalar = 1
elevator_effectiveness = 0.75
elevator_maxangle_scalar = 1.06
aileron_effectiveness = 0.8
rudder_effectiveness = 0.66
rudder_maxangle_scalar = 0.75
pitch_stability = 0.1
roll_stability = 0.1
yaw_stability = 0.1
pitch_gyro_stability = 1
roll_gyro_stability = 1
yaw_gyro_stability = 1
elevator_trim_effectiveness = 1
aileron_trim_effectiveness = 1
rudder_trim_effectiveness = 1
hi_alpha_on_roll = 0
hi_alpha_on_yaw = 0
p_factor_on_yaw = 0
torque_on_roll = 0
gyro_precession_on_roll = 0
gyro_precession_on_yaw = 0
engine_wash_on_roll = 0 ; Torque effect
wingflex_scalar = 0.75
wingflex_offset = -0.25
stall_coef_at_min_weight = 0.71
[REFERENCE SPEEDS]
full_flaps_stall_speed = 121 ; Knots True (KTAS)
flaps_up_stall_speed = 179 ; Knots True (KTAS)
cruise_speed = 455 ; Knots True (KTAS)
cruise_mach = 0.78
crossover_speed = 320 ; Knots Indicated (KIAS)
max_mach = 0.82
max_indicated_speed = 500 ; Red line (KIAS)
max_flaps_extended = 274.030126
normal_operating_speed = 360
airspeed_indicator_max = 562.5
rotation_speed_min = 145 ; Min speed required (Kts)
climb_speed = 231 ; Climb speed (Kts)
cruise_alt = 36000 ; (ft)
takeoff_speed = 150 ; Takeoff Speed (Kts)
spawn_cruise_altitude = 5000 ; Spawn Cruise Altitude (ft)
spawn_descent_altitude = 500 ; Spawn Descent Altitude (ft)
best_angle_climb_speed = 0 ; Best angle climb speed (Kts)
approach_speed = 0 ; Approach speed (Kts)
best_glide = 0 ; Best Glide (Kts)
max_gear_extended = 280 ; (Kts)
fly_assistant_use_dynamic_speeds = 1 ; 0 to display only POH values, 1 to display an estimated value with current flaps / weight
[INTERACTIVE POINTS]
number_of_interactive_points = 10
interactive_point.0 = 0.4, 27.93, -6.05, 3.02, 0, 0, 0, -86, 72, 16, 85, 3, -2, 33
interactive_point.1 = 0.4, 27.93, 6.05, 3.02, 0, 0, 0, 86, 85, 3, 72, 16, -2, 33
interactive_point.2 = 0.4, -53, -5.2, 3, 0, 0, 0, -103, 0, 0, 0, 0, 0, 0
interactive_point.3 = 0.4, -53, 5.2, 3, 0, 0, 0, 103, 0, 0, 0, 0, 0, 0
interactive_point.4 = 0.4, -29.5, 2, -1.8, 1, 0, 0, 90, 0, 0, 0, 0, 0, 0
interactive_point.5 = 0.4, 18, 1.93, -1.9, 1, 0, 0, 90, 0, 0, 0, 0, 0, 0
interactive_point.6 = 0.4, -4, -6, 6.2, 2, 0, 0, -90, 0, 0, 0, 0, 0, 0
interactive_point.7 = 0.4, -4, 6, 6.2, 2, 0, 0, 90, 0, 0, 0, 0, 0, 0
interactive_point.8 = 0, 36.3, 10.78, -5.18, 4, 0, 0, 45, 0, 0, 0, 0, 0, 0
interactive_point.9 = 0, 0, -54.59, -7.57, 3, 0, 0, -90, 0, 0, 0, 0, 0, 0
[STALL PROTECTION]
stall_protection = 1 ; Alpha Protection
off_limit = 11.5 ; Alpha below which the Alpha Protection can be disabled (If also below off_yoke_limit)
off_yoke_limit = 1 ; Yoke position (in Pct) below which the Alpha Protection can be disabled (If also below off_limit)
on_limit = 14 ; Alpha above which the Alpha Protection timer starts
on_goal = 10 ; The alpha that the Alpha Protection will attempt to reach when triggered
timer_trigger = 1.0 ; Duration (in Sec) the alpha must be above on_limit before the Alpha Protection is triggered
;===================== FLAPS =====================
[FLAPS.0]
type = 1 ; Flap type 0 = None, 1 = trailing edge, 2 = leading edge
system_type = 1 ; Flap system type 0 = electrical, 1 = hydraulic, 2 = pneumatic, 3 = manual, 4 = none
system_type_index = 80
span-outboard = 0.8 ; Outboard span area (added area) (percentage, non dimensional)
extending-time = 12 ; Flap extension time (SECONDS)
damaging-speed = 233 ; Speed above which flap is damaged (Kts)
blowout-speed = 250 ; Speed above which flap is blown out (Kts)
maneuvering_flaps = 0
lift_scalar = 0.5 ; Scalar coefficient to ponderate global flap lift coef (non dimensioned)
drag_scalar = 1.0 ; Scalar coefficient to ponderate global flap drag coef (non dimensioned)
pitch_scalar = 1 ; Scalar coefficient to ponderate global flap pitch coef (non dimensioned)
max_on_ground_position = 4 ; Dynamically set in-tool to last flap-position index by defaut when -1 is found.
flaps-position.0 = 0, -1, 0
flaps-position.1 = 10, 215, 0.25
flaps-position-autoretract.1 = 0, 210, 230
flaps-position-inhibit-and.1 = air,increasing
flaps-position.2 = 15, 200, 0.5
flaps-position.3 = 20, 185, 0.75
flaps-position.4 = 35, 177, 1
[FLAPS.1]
type = 2 ; Flap type 0 = None, 1 = trailing edge, 2 = leading edge
system_type = 1 ; Flap system type 0 = electrical, 1 = hydraulic, 2 = pneumatic, 3 = manual, 4 = none
system_type_index = 79
span-outboard = 0.75 ; Outboard span area (added area) (percentage, non dimensional)
extending-time = 12 ; Flap extension time (SECONDS)
damaging-speed = 260 ; Speed above which flap is damaged (Kts)
blowout-speed = 270 ; Speed above which flap is blown out (Kts)
maneuvering_flaps = 0
lift_scalar = 1.2 ; Scalar coefficient to ponderate global flap lift coef (non dimensioned)
drag_scalar = 0.7 ; Scalar coefficient to ponderate global flap drag coef (non dimensioned)
pitch_scalar = 1 ; Scalar coefficient to ponderate global flap pitch coef (non dimensioned)
max_on_ground_position = 4 ; Dynamically set in-tool to last flap-position index by defaut when -1 is found.
flaps-position.0 = 0, -1, 0
flaps-position.1 = 18, 215, 0.25
flaps-position.2 = 22, 200, 0.5
flaps-position.3 = 22, 185, 0.75
flaps-position.4 = 27, 177, 1
